Durable and Popular Electronic Cabinet Lock / Solenoid lock Automatic open door

Durable and Popular Electronic Cabinet Lock / Solenoid lock Automatic open door

Product Details:

Place of Origin: China
Brand Name: JUNSON
Certification: CE/FCC
Model Number: JS-304

Payment & Shipping Terms:

Minimum Order Quantity: 100pcs
Price: USD3.97-4.90/cps
Packaging Details: 100pcs/carton, 850 cartons in one 20" container
Delivery Time: 2-7 working days after received your payment
Payment Terms: T/T, paypal or western Union in advance
Supply Ability: 5,0000pcs per month
Get Best Price Contact Now

Detail Information

Product Name: Electric Cabinet Lock Working Type: Fail Secure
Voltage: 12V Current: 1A
Inside Coil: Fine Copper Coil Color: Silver
Shape: Square Weight: 0.16/kg
Packing: 100pcs Carton Size: 50L*30W*21H (cm)
High Light:

magnetic cabinet locks

,

keypad cabinet lock

Product Description

Durable and Popular Electric cabinet / Solenoid lock Automatic open door

MODEL: JS-304



JUNSON's Electric cabinet lock with fine copper coils, durable steel housing, have CE certificate, were salsed over more than 100 countries.



Specifications:





Lock Dimension 69.5L*64.5W*13H (mm)
Lockpin length 29.5mm
Fail Secure  locked when power off
Materials: Steel housing / fine copper coils
Voltage 12V
Working Current: 1A
Consuming power 1.2W
Signal out NO/COM for JS-304S
Open time 1S
Continue power on ≦10S
Operation temperature -40℃ -50℃
Operation Humidity 0-80℃
Available All kind of Cabinet
Weight: 0.16kg/pcs
Packing: 100pcs/ carton
Carton size: 50L*30W*21H (cm)



Main Size Drawing:

Durable and Popular Electronic Cabinet Lock / Solenoid lock Automatic open door 0



Main Feature:



  •  High-strength steel, and fine copper coils, durable
  • Small Volume, light weight, Less power consumption, Easy installation
  • Available for any kind of cabinet, file box.
  • Continues electrify no longer than 10S, to prevent the burn the coil
  • With small with connector, and 20mm wires, easy to connect to the control board.
  • Workable with access control, remote control or special access control power.
  • Metal housing, easy to install in the cabinet door.
  • With Emergency open switch hidden, can open by hand in emergency condition
  • Safety, bolt’s holding force at 150kg
  • Flick the door auto. With adjustment spring, can open the 0.5-4kg door automatic.

Durable and Popular Electronic Cabinet Lock / Solenoid lock Automatic open door 1



FAQ



Q:How do I pay for my purchase?
A: we accept the following payment methods: cridet card; moneybooker;T/T;western union.



Q:How much does it cost to ship to my country?
A:Please tell us your receive goods address, we will check the shipping cost for your reference





Quality Guarantee:



Warranty Service will be honored if the damage is not caused by human, JUNSON Provides 3 years

warranty for relative products. On the contrary, JUNSON will charge extra if repair. More information,

please browse our service center.



We offer many Electronic lock, like: Magnetic door lock, Electric deadbolt lock, Electric strike, Electric bolt lock, Electronic lock. Door lock. Access control.
