12V Electromagnetic Lock 280KG Holding Force With Buzzer For Access Control Systems

China 12V Electromagnetic Lock 280KG Holding Force With Buzzer For Access Control Systems supplier
12V Electromagnetic Lock 280KG Holding Force With Buzzer For Access Control Systems supplier 12V Electromagnetic Lock 280KG Holding Force With Buzzer For Access Control Systems supplier 12V Electromagnetic Lock 280KG Holding Force With Buzzer For Access Control Systems supplier 12V Electromagnetic Lock 280KG Holding Force With Buzzer For Access Control Systems supplier

Large Image :  12V Electromagnetic Lock 280KG Holding Force With Buzzer For Access Control Systems

Product Details:

Place of Origin: China
Brand Name: JUNSON
Certification: CE/SGS/ROHS/FCC
Model Number: JS-280SF

Payment & Shipping Terms:

Minimum Order Quantity: 10 pieces
Price: negotiation
Packaging Details: Packed in carton
Delivery Time: 1-7 working days once the payment received
Payment Terms: T/T, PayPal or Western Union in advance
Supply Ability: 30,000pcs per month
Contact Now
Detailed Product Description
Product Name: Magnetic Lock Application: Metal, Glass, Or Wooden Door
Holding Force: 600lbs / 280kg Feature: Fail Safe
Power Supply: 12V Or 24V Signal Out: NO, NC, Com
Armature Plate Finish: Zinc Surface Finishing: Anodized Aluminum

12V Electromagnetic Lock 280KG Holding Force With Buzzer For Access Control Systems



JS-280SF





JUNSON single door magnetic lock(electromagnetic lock) is for glass door, wooden door, fireproof door, sliding door and metal door.Special antresidual magnetism designed makes the access control automation safer and electric lock more durable.



Specifications:



Lock Dimension:

250L * 49.5W * 26.5H (mm)

Armature plate dimension:

180L * 38W *13H (mm)

Holding force

280Kg (600lbs)

Voltage :

12 / 24V  DC

Current :

12V / 450mA,   24V / 240mA

Available bracket

JS-28U, JS-28ZL, JS-28L

Signal output:

Dry Contact, NO, NC, Com

Surface Temp:

 ≦20℃

Operating Temp:

-10℃ - 55℃

Suitable Humidity:

0-90% (non-condensing)

Finishing for lock and Armature

 Zinc

Weight:

2kg

Standard Packing:

10pcs

Cartons size:

35L * 29W * 16H (cm)







Description:



1.   Fail safe, Power to lock

2.   Collinear Load Test 280kg, 600pounds

3.   Dual Voltage 12 or 24 VDC(optional)

4.   The Standard Voltage is 12VDC when Finished

5.   MOV Provides Reverse Current Protection

6.   Suitable For Wooden Door, Glass Door, Metal Door, Fireproof Door

7.   LED Indicates the Lock Status, lock Status sensor(NO/NC/COM)

8.   High Strength Material(kasolite steel), Anodized Aluminum Housing

9.   Design with no Mechanical Bolt

10.  Increase the holding Force, Dual Insulative Hosing









 12V Electromagnetic Lock 280KG Holding Force With Buzzer For Access Control Systems



Junson magnetic locks adopt international leading production equipment and packaging technology, which not only makes our locks' antioxidant capacity of the surface reach the international leading level, but also helps to increase the holding force (higher 20% than other manufacturers). Now our locks have been sold to more than 60 countries and regions around the world, they are widely used in the important places such as airports, subways, banks, prisons, intelligent buildings, intelligent community and so on, and become convenient, fast and intelligent tool for global users, gain good reputation from the customers.



12V Electromagnetic Lock 280KG Holding Force With Buzzer For Access Control Systems





FAQ



Q:How do I pay for my purchase?
A: we accept the following payment methods: cridet card; moneybooker;T/T;western union.



Q:How much does it cost to ship to my country?
A:Please tell us your receive goods address, we will check the shipping cost for your reference



Q:Is there any tracking Number for my item?

A: Yes, we ship every order with their Tracking Number, and you can view the shipment staus on the corresponding website.



Q:Does this product come with retail package?

A: We have declared the packing detail on the description of each product, please check it, thank you!



Q:I am a reseller,I would like to buy many pieces of your item, what's the wholesale price?

A: Hi,thanks for your inquiry, if you would like to buy large quantity, please send email to us, we will give you the best price, thanks!



Quality Guarantee:



Warranty Service will be honored if the damage is not caused by human, JUNSON Provides 3 years warranty

 for relative products. On the contrary, JUNSON will charge extra if repair.
