IP68 Waterproof DC12V Zinc Alloy No-Touch Exit Push Button for Door Release
Product Details:
| Place of Origin: | China |
| Brand Name: | Junson |
| Certification: | CE/ROHS/FCC |
| Model Number: | JS-H81W |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | negotiation |
| Packaging Details: | Packed in carton |
| Delivery Time: | 3-7days |
| Payment Terms: | T/T,Western Union |
| Supply Ability: | 30,000pcs per month |
|
Detail Information |
|||
| Brand: | JUNSON | Product Model: | JS-H81W |
|---|---|---|---|
| Dimensions:: | 81L*31W*24H(mm) | Output Contact:: | NO/NC/COM |
| Waterproof:: | IP68 | Operating Temp:: | -20℃~+55℃-4-131F) |
| Power:: | DC12/24V | Operating Humidity:: | 0-95%(relative Humidity) |
| Sensitive Distance:: | 5-20cm(Adjustable) | LED Indicator:: | Blue LED(Standby) Green LED(Active) |
| Highlight: | IP68 Waterproof Exit Push Button,DC12V No-Touch Exit Button,Zinc Alloy Door Release Button |
||
Product Description
IP68 Waterproof Mini No-Touch Exit Button
Model: JS-H81W | DC12V Zinc Alloy with LED Indicator
Technical Specifications
| Dimensions | 81L × 31W × 24H (mm) |
| Operating Temperature | -20℃ to +55℃ (-4°F to 131°F) |
| Power Supply | DC12V/24V |
| Operating Humidity | 0-95% (relative humidity) |
| Output Contact | NO/NC/COM |
| Sensitive Distance | 5-20cm (Adjustable) |
| Waterproof Rating | IP68 |
| LED Indicator | Blue LED (Standby) / Green LED (Active) |
| Mechanical Life | 500,000 Cycles |
| Mounting Method | Surface Mount |
| Time Delay | 0-30s (Adjustable) |
| Material | Zinc Alloy |
| Weight | 0.112KG |
| Package Quantity | 100PCS/38.5×38.5×12cm per carton |
Key Features
- 500,000 cycle testing ensures product reliability and durability
- 12V or 24V power options for flexible integration with access control systems
- Compact mini design with infrared induction technology
- Zinc alloy construction with smooth surface finish
- NO/NC/COM signal feedback for versatile installation
- IP68 waterproof rating for harsh environment applications
- Adjustable sensitive distance (5-20cm) and time delay (0-30s)
Button Dimensions
Installation Instructions
Product Overview
The door exit push button is specifically designed for low-voltage systems, with primary applications in security and access control systems. Typically configured as normally open (NO), this button transmits signals to activate door release mechanisms. The spring-return design ensures automatic resetting to the original position, guaranteeing reliable and consistent operation cycle after cycle.
Quality Assurance
Our dedicated quality control team monitors production lines continuously. Every product undergoes comprehensive inspection before shipment, including inline quality checks during manufacturing and final inspection upon completion.
- All incoming raw materials are verified upon factory arrival
- Comprehensive component, logo, and detail inspection during production
- Packaging specifications checked throughout manufacturing process
- Final quality and packaging verification before shipment
Our Services
- Professional packaging and printing solutions for export markets
- Advanced manufacturing capabilities
- Flexible payment options: T/T, Western Union, L/C, PayPal
- Premium quality materials with competitive pricing
- Small order quantities accepted
- Rapid response to inquiries and orders
- Secure and expedited shipping services
- Custom OEM design services available
