Durable 300lbs/180kg Electromagnetic Lock for Sliding Doors, Secure Home Use JS-180S
Product Details:
| Place of Origin: | China |
| Brand Name: | JUNSON |
| Certification: | CE/SGS/ROHS/FCC |
| Model Number: | JS-180S |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 pieces |
|---|---|
| Price: | negotiation |
| Packaging Details: | Packed in carton |
| Delivery Time: | 1-7 working days once the payment received |
| Payment Terms: | T/T, PayPal or Western Union in advance |
| Supply Ability: | 30,000pcs per month |
|
Detail Information |
|||
| Armature Plate Finish: | Zinc | Suitable Humidity: | 0~90%(non-condensing) |
|---|---|---|---|
| Export Markets: | Global | Feature: | Fail Safe |
| Weight: | 1.2kg | Application: | Metal, Glass, Or Wooden Door |
| Holding Force: | 300lbs / 180kg | Available Bracket: | JS-18U, JS-18L. JS-18ZL |
Product Description
Household Sliding Door Electromagnetic Lock, 300lbs/180kg Holding Force JS-180S
The JS-180S Electromagnetic Lock is designed with the principle of an electromagnet. When current passes through the silicon steel sheet, the lock generates a strong magnetic force to securely hold the iron plate. Even with a small current, it produces a powerful suction, ensuring reliable door control. Suitable for sliding doors and household security applications.
Specifications of Electromagnetic Lock 300LBS:
|
Lock Dimension |
170L * 40W * 21H (mm) |
|
Armature plate dimension |
130L * 33W *12 H (mm) |
| Weight | 1.2kg |
|
Cartons size |
40L * 18.2W * 28H (cm) |
|
Standard Packing |
20pcs |
|
Finishing for lock and Armature |
Zinc |
|
Available bracket |
JS-18U, JS-18ZL, JS-18L |
|
Signal output (for JS-180S): |
Dry Contact, NO, NC, Com (for JS-180S) |
|
Surface Temp |
≦20℃ |
|
Operating Temp |
-10℃ - 55℃ |
|
Suitable Humidity |
0-90% (non-condensing) |
|
Holding force |
180Kg (300lbs) |
|
Current |
12V / 380mA, 24V / 190mA |
|
Voltage |
12 / 24V DC |
A grade Aluninum housing, strong enough for installation
imported E shape silicon steel materials
Full-automatic electric soldering, to make sure E shape lock body smoothly
Descriptions of Electromagnetic Lock 300LBS
1. Dual Voltage 12 or 24 VDC(optional)
2. Fail safe, Power to lock
3. Collinear Load Test 180kg, 300pounds
4. The Standard Voltage is 12VDC when Finished
5. Aluminium Anodizing for the plate and housing
6. Suitable For Wooden Door, Glass Door, Metal Door, Fireproof Door
7. High Strength Material(kasolite steel), Anodized Aluminum Housing
8. Design with no Mechanical Bolt
9. Increase the holding Force, Dual Insulative Hosing
10.With monitor sensor feedback, can monite the door's status (NO/NC)
11.MOV Provides Reverse Current Protection
Junson magnetic locks adopt international leading production equipment and packaging technology, which not only makes our locks' antioxidant capacity of the surface reach the international leading level, but also helps to increase the holding force (higher 20% than other manufacturers). Now our locks have been sold to more than 60 countries and regions around the world, they are widely used in the important places such as airports, subways, banks, prisons, intelligent buildings, intelligent community and so on, and become convenient, fast and intelligent tool for global users, gain good reputation from the customers.
