Door Sensor ABS 3.84W 12V 0.32A Fail Safe Cabinet Lock

Door Sensor ABS 3.84W 12V 0.32A Fail Safe Cabinet Lock

Product Details:

Place of Origin: China
Brand Name: JUNSON
Certification: CE/FCC
Model Number: JS-3033

Payment & Shipping Terms:

Minimum Order Quantity: 5pcs
Price: US$2.39-5.00/cps
Packaging Details: 100pcs/carton
Delivery Time: 2-5 working days after received your payment
Payment Terms: T/T, paypal or western Union in advance
Supply Ability: 5,0000pcs per month
Get Best Price Contact Now

Detail Information

Product Name: Fail Safe Cabinet Lock Temperaturerise: 40K
Working Type: Fail Safe Lockpin: Dia9.5mm,throw:9mm
Voltage: 12V Lifetimes: 500,000times
Operation Humidity: -20-80℃ Packing: 50pcs Per Cartons
Carton Size: 500L*300W*210H (mm) Materials: ABS Plastic Housing / Zinc Alloy Bottom
Lock Size:: 7.4L*3.55W*3.1H (cm)
High Light:

0.32A Fail Safe Cabinet Lock


ABS Fail Safe Cabinet Lock


3.84W Door Sensor Cabinet Lock

Product Description

12V 0.32A Door Sensor output ABS plastic housing Fail safe Cabinet lock


Model: JS-3033


Main Feature:


1. High strength steel, fine copper wire coil, durable
2. Small size, light weight, low power consumption, easy installation
3. It can be used for any type of equipment locker.
4. Fail-safe type, continuous startup
5. Access control, remote control or special access control power supply.
6. Gasket with lock, suitable for any fixed environment
7. Equipped with door sensor, NO/COM to monitor the status of the door.
8. Safety, pulling force of bolts at 800kg.






Parameter List


Lock Dimension 74L*35.5W*31H (mm)
Lockpin: Dia9.5mm, throw: 9mm
Lock Catch Size 33L *35.5W *30H (mm)
Working Type Fail safe / locked when power on
Materials: ABS plastic housing / Zinc Alloy bottom
Voltage 12V
Working Current: 0.32A
Consuming power 3.84W
Signal out NO/COM, door sensor output
Temperature rise: 40K
Life times 500,000 times
Operation temperature -40℃ -50℃
Operation Humidity -20-80℃
Available equipment cabinet
Weight: 0.30kg/pcs
Box size: 103*90*43 mm
Packing: 50pcs per cartons
Carton size: 50L*30W*21H (cm)



Door Sensor ABS 3.84W 12V 0.32A Fail Safe Cabinet Lock 0





Door Sensor ABS 3.84W 12V 0.32A Fail Safe Cabinet Lock 1




Quality Guarantee:


Warranty Service will be honored if the damage is not caused by human, JUNSON Provides 2 years warranty for relative products. On the contrary, JUNSON will charge extra if repair. More information, please browse our service center.


We offer many Electronic lock, like: Magnetic door lock, Electric deadbolt lock, Electric strike, Electric bolt lock, Electronic lock. Door lock. Access control.
