3.84W Fail Safe Electric Cabinet Lock 12V DC High Strength Steel With Door Status Sensor

3.84W Fail Safe Electric Cabinet Lock 12V DC High Strength Steel With Door Status Sensor

Product Details:

Place of Origin: China
Brand Name: JUNSON
Certification: CE/FCC
Model Number: JS-3033

Payment & Shipping Terms:

Minimum Order Quantity: 5pcs
Price: US$2.39-5.00/cps
Packaging Details: 100pcs/carton
Delivery Time: 2-5 working days after received your payment
Payment Terms: T/T, paypal or western Union in advance
Supply Ability: 5,0000pcs per month
Get Best Price Contact Now

Detail Information

Product Name: Fail Safe Electric Cabinet Lock Working Type: Unlock When Power On
Lock Size:: 74L*35.5W*31H (mm) Consuming Power: 3.84W
Voltage: 12V DC Current: 0.32A
Available: Equipment Cabinet Operation Temperature: -40℃ -50℃
Weight:: 0.30kg / Cps Carton Size: 50L*30W*21H (cm)
Packing: Carton
High Light:

magnetic cabinet locks

,

keypad cabinet lock

Product Description



3.84W Fail Safe Electric Cabinet Lock 12V DC High Strength Steel With Door Status Sensor 0



Fail safe Electric Cabinet lock



Model: JS-3033



Parameter List



Lock Dimension 74L*35.5W*31H (mm)
Lockpin: Dia9.5mm, throw: 9mm
Lock Catch Size 33L *35.5W *30H (mm)
Working Type Fail safe / locked when power on
Materials: ABS plastic housing / Zinc Alloy bottom
Voltage 12V
Working Current: 0.32A
Consuming power 3.84W
Signal out NO/COM, door sensor output
Temperature rise: 40K
Life times 500,000 times
Operation temperature -40℃ -50℃
Operation Humidity -20-80℃
Available equipment cabinet
Weight: 0.30kg/pcs
Box size: 103*90*43 mm
Packing: 50pcs per cartons
Carton size: 50L*30W*21H (cm)



Main Feature:

1. High-strength steel, and fine copper coils, durable

2. Small Volume, light weight, Less power consumption, Easy installation

3. Available for any kind of equipment locker.

4. Fail safe type, power on continuously

5. Workable with access control, remote control or special access control power.

6. With spacer for lock catch, suitable any fixed environment

7. With door sensor, NO/COM, monitor door status.

8. Safety, bolt’s holding force at 800kg .



3.84W Fail Safe Electric Cabinet Lock 12V DC High Strength Steel With Door Status Sensor 1

3.84W Fail Safe Electric Cabinet Lock 12V DC High Strength Steel With Door Status Sensor 2





Quality Guarantee:



Warranty Service will be honored if the damage is not caused by human, JUNSON Provides 2 years warranty for relative products. On the contrary, JUNSON will charge extra if repair. More information, please browse our service center.



We offer many Electronic lock, like: Magnetic door lock, Electric deadbolt lock, Electric strike, Electric bolt lock, Electronic lock. Door lock. Access control.
