8 Wires / 5 wires Electric Bolt Lock Zinc Alloy Fail Secure Electronic Bolt Locks

China 8 Wires / 5 wires Electric Bolt Lock Zinc Alloy Fail Secure Electronic Bolt Locks supplier
8 Wires / 5 wires Electric Bolt Lock Zinc Alloy Fail Secure Electronic Bolt Locks supplier 8 Wires / 5 wires Electric Bolt Lock Zinc Alloy Fail Secure Electronic Bolt Locks supplier

Large Image :  8 Wires / 5 wires Electric Bolt Lock Zinc Alloy Fail Secure Electronic Bolt Locks

Product Details:

Place of Origin: China
Brand Name: JUNSON
Certification: CE/ROHS/FCC
Model Number: JS-200SL

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Price: negotiation
Packaging Details: Packed in carton case
Delivery Time: 2-7 working days after received your payment
Payment Terms: T/T, paypal or western Union in advance
Supply Ability: 30,000pcs per month
Contact Now
Detailed Product Description
Product Name: Electric Bolt Lock Type: Fail Secure
Power Supply: 12V/24V Timer Adjuster: 0-9S
Application: Metal Or Wooden Door Time: 0-9s
Signal Out: NO/NC/COM Open Sensor: Magnet Switch Sensor
Material: Zinc Alloy Suitable For: Glass Door,/ Wooden Doors / Metal Doors,Secure Locking Of Furniture (Wooden & Aluminum& Metal Furniture Frame),Access Control,External Installation For Narrow Door
Warranty: 2 Years Finish: Surface Finished

8 Wires / 5 wires Electric Bolt Lock Zinc Alloy Fail Secure Electronic Bolt Locks



This door lock is special in design with durable material . It can protect your home or business shops . Low operational and standby current . It's especially suitable for glass doors . Great choice for you .



Specification:

Fail Safe: unlock when power off
Lock body size: 157.5Lx31Wx40H(mm)
Face plate size: 200Lx34Wx3.4H(mm)
Blot out plate size: 210Lx42Wx0.8H(mm)
Magnet bracket: 90Lx24Wx3H(mm)
Lock pin: 15.5mmDIA,stainless steel out throw15mm
Voltage: DC12V
Current:

Start: 0.85A

Standby: 0.09A

Holding force 1000kg
Solenoid: Continuous duty
Auto relock Timer jumper adjustable (0/3/6/9S)
Surface Temp: ≦20℃
Induction Distance 8mm
Operating temp: -10~+25℃(14-131F)
Operating Humidity: 0~90%(non-condensing)
Face place material: High Aluminum, Carrulous Line Finished
Weight: 0.9kg
Standard Packing: 10pcs.
Carton size: 53Lx30Wx14H(cm)



Feature

▶Low Temperature, safe & Durable

▶Low Power, Environmental Protection

▶MOV Provides Reverse Current Protection

▶Superior Strength Aluminum Alloy, Solid Stainless Steel Bolt

▶Request-to-open, Auto-relock if no Action within 5 sec

CE Certificate by European Union, MA China Public Security office




8 Wires / 5 wires Electric Bolt Lock Zinc Alloy Fail Secure Electronic Bolt Locks
8 Wires / 5 wires Electric Bolt Lock Zinc Alloy Fail Secure Electronic Bolt Locks
 8 Wires / 5 wires Electric Bolt Lock Zinc Alloy Fail Secure Electronic Bolt Locks






Quality Guarantee :

Warranty Service will be honored if the damage is not caused by human, JUNSON Provides 2 years
warranty for relative products. On the contrary, JUNSON will charge extra if repair. More information,
please browse our service center.
    We offer many Electronic lock, like: Magnetic door lock, Electric deadbolt lock, Electric strike, Electric
bolt lock, Electronic lock.
