1200 lb LED Fail Secure Electromagnetic Lock for Sliding Door
||500L * 47W * 27H (mm)
|Armature plate dimension:
||185L * 38W *13H (mm)
||12 / 24V DC
||12V / 400mA, 24V / 200mA
||JS-280U, JS-280ZL, JS-280L
||Dry Contact, NO, NC, Com
||-10℃ - 55℃
|Finishing for lock and Armature
||35L * 30W * 16H (cm)
Features of Electric Magnetic Locks
- High-strength housing with aluminum anodizing finish.
- MOV surge protection.
- Dual voltages of 12V/24V.
- No residual magnetism.
- Very easy to operate: Instantly unlocked when power is off.
- No mechanical failure.
- Fail-safe, satisfy applicable fire regulations.
1. Fail safe, Power to lock
2. Collinear Load Test 280kg, 600pounds
3. Dual Voltage 12 or 24 VDC(optional)
4. The Standard Voltage is 12VDC when Finished
5. MOV Provides Reverse Current Protection
6. Suitable For Wooden Door, Glass Door, Metal Door, Fireproof Door
7. LED Indicates the Lock Status, lock Status sensor(NO/NC/COM)
8. High Strength Material(kasolite steel), Anodized Aluminum Housing
9. Design with no Mechanical Bolt
10. Increase the holding Force, Dual Insulative Hosing
The design of magnetic locks(Electromagnetic lock) is the same as the electromagnet. By using the principle of electromagnetic, when current passes through the silicon steel sheet, magnetic locks will produce powerful suction, thereby helps to tightly absorb iron plate. Even small current will produce huge magnetic, which can effectively control the door.
Junson magnetic locks adopt international leading production equipment and packaging technology, which not only makes our locks' antioxidant capacity of the surface reach the international leading level, but also helps to increase the holding force (higher 20% than other manufacturers). Now our locks have been sold to more than 60 countries and regions around the world, they are widely used in the important places such as airports, subways, banks, prisons, intelligent buildings, intelligent community and so on, and become convenient, fast and intelligent tool for global users, gain good reputation from the customers.
